打開電池盒后蓋，正朝前，裝好電池，擰緊后蓋。將扳手方榫套入相應尺寸規格得套筒，將套筒裝入螺母或螺栓頭上

Open the back cover of the battery box, facing forward, install the battery, and tighten the back cover. Insert the square tenon of the wrench into the corresponding size and specification of the socket, and install the socket onto the nut or bolt head

【開啟電源】：按【開機】鍵液晶屏顯示讀數0000后即可使用

[Power on]: Press the [Power on] button and the LCD screen will display a reading of 0000 before use

【預置】：按【模式】鍵，使工作狀態變?yōu)轭A置狀態，根據檢測扭矩值得大小，

【 Pre setting 】: Press the 【 Mode 】 key to change the working state to a preset state. Depending on the detected torque value,

按【設定】鍵,顯示PP.PH,再按此鍵確認后,進入預置報警設定菜單,按模式鍵(-),【單位】鍵(+),每次一個單位。

Press the [Set] button to display the PP PH, press this key again to confirm and enter the preset alarm setting menu. Press the mode key (-) and the unit key (+), one unit at a time.

輸入預置值,按設定鍵確認后退出菜單。加力當預置燈點亮同時報警聲響起時，表示緊固力矩預定值，可以停止加力。

Enter the preset value, press the set button to confirm, and then exit the menu. When the preset light is on and the alarm sounds, it indicates the predetermined tightening torque value and can stop applying force.

【校零】：扳手自然水平放置狀態下，短按【開機】鍵，顯示0000。

【 Zero calibration 】: When the wrench is naturally placed horizontally, short press the 【 Power on 】 button to display 0000.

【單位選擇】：根據使用要求，按"單位"鍵，選擇扭矩單位N.m、Ibf.ft、Ibf.in。單位選擇：根據使用要求，按"【單位】鍵，選擇扭矩單位N.m、Ibf.ft、Ibf.in。

【 Unit Selection 】: According to the usage requirements, press the "Unit" button to select torque units such as N.m, Ibf.ft, and Ibf-in. Unit selection: According to the usage requirements, press the 【 Unit 】 button to select torque units such as N.m, Ibf.ft, and Ibf-in.

【峰值】：按【模式】鍵，使工作狀態變?yōu)榉逯当３譅顟B(tài)，所施加得大力矩在卸力好繼續顯示在液晶屏上，清除時短按【開機】鍵。

【 Peak 】: Press the 【 Mode 】 button to change the working state to a peak holding state. The applied large torque will continue to be displayed on the LCD screen after unloading. When clearing, press the 【 Power 】 button briefly.

【關機】：a,自動關機：當未檢測扭矩值時，3分鐘后自動關機。

[Shutdown]: a. Automatic shutdown: When the torque value is not detected, it will automatically shut down after 3 minutes.

手動關機：按【開機】鍵3秒，即可手動關機。

Manual shutdown: Press the power button for 3 seconds to manually shut down.
