扭剪扳手是設備維修及加工組裝行業中必不可少的工具,以一定的扭矩擰緊各種螺栓,能保證機械設備的可靠連接和正常工作。隨著扭剪扳手技術的發展,其在工程領域的應用勢必會越來越廣泛。
Torsion wrench is an essential tool in equipment maintenance and assembly industry. Tightening various bolts with a certain torque can ensure the reliable connection and normal work of mechanical equipment. With the development of torsion wrench technology, its application in engineering field will be more and more widely.
(1)結構簡單的高精度扭剪扳手
(1) High precision torsion shear wrench with simple structure
一些氣動式和液壓式扭剪扳手都附帶著氣泵和液壓泵來提供動力,此類設備附件較多,不便于移動工作。扭剪扳手可在保證精度的前提下進一步簡化結構,使用輕巧方便,降低生產成本。
Some pneumatic and hydraulic twist shear wrenches are equipped with air pump and hydraulic pump to provide power. This kind of equipment has many accessories and is not easy to move. The torsion wrench can further simplify the structure on the premise of ensuring the accuracy, which is light and convenient to use and reduces the production cost.
(2)動力供應通用化
(2) Generalization of power supply
對于數顯式扭剪扳手都有傳感器和控制電路，通常采用充電電池供電。在電池電量不足時會直接影響精度。扭剪扳手的充電方式應該向著利用太陽能或機械能的充電的方式發展,太陽能的供電方式.會使扳手在光線充足的地方時刻在充電,機械能的充電方式可以利用擰緊螺栓過程中產生的機械能進行充電。這兩種方式可使扭剪扳手始終保持滿電狀態,不會出現因電量不足導致精度降低的情況,并且可以節約能源。
There are sensors and control circuits for digital display torsional shear spanners, which are usually powered by rechargeable batteries. When the battery is low, it will directly affect the accuracy. The charging mode of torsion wrench should be developed towards the charging mode of using solar energy or mechanical energy. The power supply mode of solar energy will make the wrench charge in the place with sufficient light all the time. The charging mode of mechanical energy can use the mechanical energy generated in the process of tightening the bolt to charge. These two methods can make the wrench always keep full power state, and will not reduce the accuracy due to insufficient power, and can save energy.
(3)性能穩定的人性化產品
(3) Humanized products with stable performance
作為一種五金工具,設應增強產品的實用性及穩定性。實用的用戶手冊可以給用戶更加人性化的使用指南。除扳手的操作指南外,還應該提供針對于不同規格螺栓時應該施加扭矩的大小等參數。另外,扭剪扳手的設計應該充分遵循人機工程.學的設計原則,手柄長度可以隨著所施加的扭矩值的大小的設定來調整。通過調整力臂的大小可使操作更加便捷。
As a kind of hardware tool, the practicability and stability of the product should be enhanced in the design. Practical user manual can give users more user-friendly guide. In addition to the operation guide of the wrench, the parameters such as the torque to be applied for bolts of different specifications should also be provided. In addition, the design of the wrench should fully follow the design principle of ergonomics. The length of the handle can be adjusted with the setting of the applied torque value. By adjusting the size of the arm, the operation is more convenient.
(4)參數設定智能化
(4) Intelligent parameter setting
對于規格不同的螺栓,所施加的擰緊力矩大小.也不--樣。在更換套筒時扭剪扳手的電控系統應該對套筒的規格進行識別,根據套簡規格與螺栓規格的關聯關系自動設定所需施加的擰緊力矩大值，實現擰緊力矩峰值自動設定,避免對經驗的依賴。
For bolts of different specifications, the tightening torque applied is not the same. When replacing the socket, the electric control system of the wrench should identify the specification of the socket, and automatically set the maximum tightening torque according to the relationship between the sleeve specification and the bolt specification, so as to realize the automatic setting of the peak tightening torque and avoid the dependence on experience.
扭剪扳手的螺栓夾持部分參照普通活口扳手的夾持部分,通過調整扳手夾持部分的開口尺寸來適應螺栓頭的大小。扭剪扳手的電控系統通過識別扭剪扳手夾持部分的開尺寸來感應被擰緊的螺栓的尺寸進而自動設定相應的擰緊力矩的峰值。這種活口扭剪扳手操作簡單，智能化程度高,發展前景廣闊。
The bolt clamping part of the torsion shear wrench refers to the clamping part of the ordinary open end wrench, and the opening size of the clamping part of the wrench is adjusted to adapt to the size of the bolt head. The electronic control system of the wrench senses the size of the tightened bolt by identifying the open size of the clamping part of the wrench, and then automatically sets the corresponding peak value of the tightening torque. This kind of wrench is easy to operate, high intelligent and has a bright future.
